Southern germany
We supplied and installed components for a municipal wastewater treatment plant that has been operating reliably since 1999. The plant has a capacity of 430,000 m³ and a maximum inflow of 5,000 liters per second.
Installed components
Key Data
Inlet structure
- Plant capacity
- 431,000 m³/d (5 m³/s)
- Installed
- 01/1999
Fine Screen
Type MC
- Inflow per screen
- 1,275 m³/s
- No. of machines
- 4
- Screen width
- 1,965 mm
- Discharge height
- 5,531 mm
- Slot opening
- 6 mm
Screenings Washer
Type RWK 40
- No. of machines
- 2
- Nominal capacity per machine
- 10 m³/h
Spiral Conveyor
- Type
- U360
- No. of machines
- 2
- Nominal capacity per machine
- 25 m³/h
- Length
- 13,500 mm
- Type
- U285
- No. of machines
- 2
- Nominal capacity per machine
- 9 m³/h
- Length
- 10,000 mm
- Type
- U580
- No. of machines
- 1
- Nominal capacity per machine
- 50 m³/h
- Length
- 9,000 mm
